Product Parameters
Model Size: | 2150*870*1480mm | Manufacture: | SHINERAY |
Axis pitch: | 1490mm | Engine model: | 267MR-A |
Ground clearance: | 196mm | Structure of engine: | In-line double cylinder |
Maximum speed: | 150km/h | Stroke: | Four stroke |
Braking mode: | Hydraulic disc brake +ABS | Maximum Power: | 35Kw/8500rpm |
Form of tire: | Vacuum tire | Maximum Torque : | 45N.m/7000rpm |
Tire Specifications: | 120/70-17; 160/60-17 | Mode of Cooling: | Water cooled |
Hub Form: | Aluminium alloy | Displacement : | 500cc |
Hub specifications: | Precise Displacement : | 471ml | |
Lighting form: | LED | Valve valve structure: | DOHC 8 valves |
Suspension System: | Fr: Upside down | Cylinder Diameter & Stroke : | 67X66.8mm |
Rr:Central subtraction | Oil Supply Mode: | Fuel injection | |
Tank capacity: | 18L | Ratio of compression: | 10.7:1 |
ECO Consumption: | 4.2L/100km | Mode of ignition: | EFI |
Battery Specifications: | 12V9AH | Start up Mode: | Electric |
Form of Instrument: | TFT color screen | ROZ: | No. 92 |
Rated Load: | 150kg | Effluent standard: | The Ⅳ |
Net Weight: | 196kg | Lubrication method: | Pressure & splash |
Gross Weight: | 240kg | Transmission type: | 6 speed international gear |
Method of Packing: | Iron frame and carton | Type of clutch: | Manual wet multi-chip |
Package Size: | 2100*680*1150mm | Mode of transmission: | Chain drive |
Loading Quantity: | 20GP:14 sets | Balance shaft: | Built in Balance shaft |
40HQ:34 sets | Net weight: |
